제품 상세 정보:
결제 및 배송 조건:
|
롤러재: | 폴리우레탄 | 금속 재료: | Q235 열침 아연 도금 |
---|---|---|---|
롤러 사이즈: | 지름 245/350 MM | 상술: | 빔 1/2/3/4/5PCS |
생산 시간: | 25 일로 | 색: | 오렌지 / 노랑 / 빨간색 / 녹색 |
간격: | 650/700/1000 밀리미터 | 수명: | 10년 |
등급: | 국제적 수준 4 | 맞추어줍니다: | 허락됩니다 |
하이 라이트: | 오렌지색 폴리유레테인 롤러 안전장벽,반대 충돌 롤러 안전장벽,Q235 롤러 가드레일 |
Orange polyurethane roller safety bar
No. | Name | Specifications(mm) | Material |
1 | Roller | 345*490/350*510(Customized) | Polyurethane |
2 | Post | 140*2000*4.5(Customized) | Q235 |
3 | PVC Tube | 160*500*6.5(Customized) | PVC |
4 | Beam | 100*80*4.0 | Q235 |
5 | Rolling Circle | 182×145×6.0 | Polymer Ethylene |
6 | End Socket | 1300×230×4.0 | Q235 |
7 | Post Cap | 145×145 | Rubber |
8 | Bolt | M18*120 | Q235 |
M18*180 | Q235 | ||
M18*80 | Q235 | ||
9 | Nut | M20 | Q235 |
Item | Specifications |
Apparent Density (KG/m³) | ≥125 |
Tensile Strength(MPa) | ≥1.15 |
Elongation(%) | ≥320 |
Compression Permanent Distortion (%) | ≥38 |
Resilience(%) | ≥72 |
Product use
A |
Road central safety roller.the road central safety roller is to divide the car line and prevent safety driving from opposite impact |
B |
Road cross safety roller.the road cross safety roller is installed on the cross to prevent the cars from rushing to the greenbelt. |
C |
Safety roller for highway.it is very fast driving in the highway, and the safety roller is to protect the drivers&passengers from |
